![2013072838744825[1]](http://cbu01.alicdn.com/img/ibank/2013/403/611/1087116304_1086601265.jpg)
![2013072838753077[1]](http://cbu01.alicdn.com/img/ibank/2013/313/611/1087116313_1086601265.jpg)
HAND LINE BLOCKS
? Block and sheave constructed of rugged nylon fiberglass reinforced high
dielectric material
? Reinforced 1/2” diameter axle and swivel bearings
? 3” sheaves - block can accommodate rope up to 5/8” diameter
? Provided with either side opening or closed block
? Blocks are rated with 3-1 safety factor
? Working load limit 1,000 lbs.
|
CAT NO |
DESCRIPTION |
LBS |
|
3550 |
SIDE OPENING BLOCK WITH SWIVEL HOOK AND SAFETY SNAP |
1.8 |
|
3551 |
CLOSED BLOCK WITH SWIVEL HOOK AND SAFETY SNAP |
1.8 |
|
3553 |
SIDE OPENING BLOCK WITH SWIVEL EYE ONLY |
1.3 |
|
3554 |
CLOSED BLOCK WITH SWIVEL EYE ONLY |
1.3 |
|
3550-1 |
SIDE OPENING BLOCK WITH SWIVEL MEAT HOOK |
1.8 |
|
3551-1 |
CLOSED BLOCK WITH SWIVEL MEAT HOOK |
1.8 |
|
10-147 |
MEAT HOOK ONLY FOR BLOCKS |
1.0 |
COMPLETE HAND LINES
HAND LINE WITH MODEL 3550 BLOCK, 1/2”
POLYPROPYLENE ROPE, HAND LINE HOOK
(P10060), AND HAND LINE SNAP (P30142)
CAT NO WORKING
HEIGHT
OVERALL ROPE
LENGTH
LBS
3555 30’ 60’ 5.0
3556 40’ 80’ 5.5
3557 50’ 100’ 6.0
HAND LINE WITH MODEL 3551 BLOCK, 1/2”
POLYPROPYLENE ROPE, HAND LINE HOOK
(P10060), AND HAND LINE SNAP (P30142)
3558-1 30’ 60’ 4.5
3559-1 40’ 80’ 5.0
3560-1 50’ 100’ 5.5
*OTHER LENGTHS AND STYLES OF ROPE
AVAILABLE UPON REQUEST.
HAND LINE HOOK
? Hand line hook only constructed from manganese
bronze alloy, use with up to 1/2” rope
? Working load limit 600 lbs.
|
CAT NO |
DESCRIPTION |
LBS |
|
P10060 |
HAND LINE HOOK ONLY |
0.5 |
HAND LINE SNAP
? Hand line snap only, drop forged alloy steel
? Working load limit 600 lbs. (See Page 802)
? 1” diameter hole - snap opening 5/8”
|
CAT NO |
DESCRIPTION |
LBS |
|
P30142 |
HAND LINE SNAP |
0.4 |
