CAPACITOR DISCHARGE TOOL
?  The capacitor discharge tool is designed to safely drain the capacitive charge after the circuit is de-energized
?  An optional add on resistor to limit discharge current is available
?  Factory assembled to include the following components:  Fiberglass Pole with hand guard, 1/4” Stainless
Steel Hook with a 1 3/8” opening, Rubber Tool Holder,  #2 Str. Copper Grounding Cable with safety yellow
neoprene jacket, 2 hole Tin Plated Copper Lug is terminated on one end with a heat shrink sleeve
?  For Custom Build - Contact factory with required clamp, length of fiberglass pole and required length of
grounding cable for a part number

ELECTRO STATIC PRECIPITATOR GROUNDING TOOL
?  Designed to safely remove the static charge after de-energizing for service work
?  Grounding tool is factory assembled to include the following components:  Brass alloy “U” shaped hook
to engage precipitator plates, Fiberglass pole for installation, #2 Str. Copper Grounding Cable with safety
yellow neoprene jacket, Ground Clamp
?  For Custom Build - Contact factory with required clamp, length of fiberglass pole and required length of
grounding cable for a part number
